Continuous Resistance Annealer
As its name suggest, it is a resistance Annealer for RBD wire sizes. In this continuous Annealing with wire drawing as well as offline annealing can also do it. For Continuous in Line Annealing, wire drawing must be synchronized with wire drawing but it offline it will Annealing machine with Take up.
Key Features
- User Friendly
- No vacuum leakage issues
- No power tripping problems
- No heat loss issues
- Uniform annealing process
- Low maintenance requirements
Technical Specifications
| MODEL |
NO.OF WIRE |
WIRE DIA. |
SPEED |
ELECTRICAL LOAD |
| RA - 250 |
1 |
1.20-2.20mm |
15mps |
100kVA |
| RA - 300 |
1 |
1.20-2.64mm |
15mps |
150kVA |
| RA - 400 |
1 |
1.20-3.50mm |
20mps |
200kVA |
| RA - 500 AC |
1 |
1.20-4.50mm |
25mps |
250kVA |
