Offline Annealing Machine

Providing you the best range of Offline Annealing machines with different model as per different wire sizes & our machines can be modified according customer needs.

Our machines are built with extreme technical and quality control processes to ensure high performance from them. This off line Annealing is capable for annealing many wires at a time that assist in saving cost, resources and most importantly the precious time.

The spools fitted in the take up stands of these Offline Annealer machines are driven by an individual torque motor dedicated to drive each of the all spools.

This Annealer offers many advantages :
  • " All non ferrous material can anneal.
  • " Wires are free from colour variation.
  • " Energy efficient.
  • " No leakage of vacuum.
  • " No effect of weather.

In this various model of this technique in annealing wires at various sizes.



Techinical Specifications
Intermediate Wire Sizes
MODEL NO.OF WIRE WIRE DIA. SPOOL DIA. PRODUCTION IN DAY SPOOL Gr. Wt.
MA-8 8 0.50-2.00mm 400mm 3000Kgs@2.00mm 150 kg
MA-12 12 0.50-2.00mm 400mm 4500Kgs@2.00mm 150 kg
MA-16 16 0.50-2.00mm 400mm 6000Kgs@2.20mm 150 kg

Fine Wire Sizes
MODEL NO.OF WIRE WIRE DIA. SPOOL DIA. PRODUCTION IN DAY SPOOL Gr. Wt.
MA-20 20 0.30-0.72mm 200-250mm 2000Kgs@0.72mm 32 kg
MA-24 24 0.15-0.53mm 100-200mm 1500Kgs@0.30mm 18 kg
MA-32 32 0.15-0.53mm 100-200mm 2000Kgs@0.30mm 18kg
